Automatic Filling And Sealing Packaging Machine F | RFQ Sourcing Details
Sealing Jaws · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Product specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Sealing Jaws. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Detail Information Packaging Form: Cup Box Customization: Logo / Size / Parts Brand/ Material Packaging Type: Plastic Cup, Paper Cup, Aluminum And Plastic Cup Box Products Operation: Easy Operation Feature: Automatic,PLC,Touch Screen Size: 2800*1030*1700 Mm Sealing Speed: About 30~35 Cans/min Suitable For Cup Height: 40-200 Mm(can Be Customized） Bottle Height: 50-200 Mm Adjustable Machine Weight: 480 Kg Shrink Film: Foil Film Motor Power: 2.3 KW Lead Time: 30 Working Days Market: Brazil,Ecuador,France,USA Automatic rotary double heads premade film heat sealing machine 1.
Main machine appearance main materials are SUS304 stainless steel and T6 hard aluminum alloy;2. Cup/Bottle diameter :50-100mm(only limit at one bottle diameter, need to replace star wheel & sealing head mold for different bottle diameter,replace time is around 30 mins);3.
Bottle height : 50-200mm adjustable(can customize for special height);4. Suitable for bottle and cup: plastic bottle or cup, tin can, aluminum can, paper can, paper cup, glass bottle or cup 5. Bottle requirements: hard bottle body, bottle mouth is smooth;6.
Sealing head:2 heads 7.Sealing speed: about 30~35 cans/min(Speed will be different according to different bottles size & premade film type);8.
Aluminum foil requirement: Aluminum foil materials should be corresponding to the can materials(For example: PET material can use the PET film, PE material can use PE film), aluminum foil thickness: 0.1-0.4mm. 9.
Automatic film release system: It adopts the starting device to automatically drop the film and release the film accura sealing device, heat sealing plate and heat sealing head, and pneumatic sealing motion execution parts. 11. Rated voltage: Single phase AC220V 50.
Hz, Conveyor motor power 200W, heating head power 800W, star wheel power 1300W,Total power:about 2300W;12. Machine size:2800*1030*1700mm, Poly wood case packing size: 2250*1200*1940mm;13. Net weight:380KG, Gross weight :480KG;14. Seal time 1.2-2s, temperature set at 180-210℃;15.
Height of conveyor distant to ground is 900mm(+50mm), conveyor belt width:114mm;16. This machine need additionally configure air compressor, the minimum air source pressure required 0.6MPa.
Automatic | Applications and Buyer Notes
Automatic is organized as a sourcing-ready Sealing Jaws reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and lead-time questions
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- Sealing JawsBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- Bottle Height
- 50-200 Mm Adjustable Machine Weight: 480 KgBased on visible page data; confirm exact value in the RFQ.
- Brand Name
- TengzhuoBased on visible page data; confirm exact value in the RFQ.
- Certification
- CE, RoHSBased on visible page data; confirm exact value in the RFQ.
- Delivery Time
- 35 working daysBased on visible page data; confirm exact value in the RFQ.
- Feature
- Automatic,PLC,Touch Screen Size: 2800*1030*1700 MmBased on visible page data; confirm exact value in the RFQ.
- Lead Time
- 30 Working Days Market: Brazil,Ecuador,France,USABased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
